5-Port Gigabit Industrial Switch

SST-1GT4GT, a robust and reliable 5-port industrial Ethernet switch designed to meet the demanding
requirements of industrial environments. Engineered for superior performance and durability, this switch
ensures seamless connectivity and data transmission at speeds of up to 1000Mbps.

1, 4*1Gbps RJ45 ports+1*1Gbps uplink RJ45 port

2, Comply with IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, and IEEE 802.3x standards

3, Ethernet Ports support 10/100/1000Mbps self-adaptive

4, Industrial grade protection design, operating temperature from -40~75°C

5, High strength cast iron shell, DIN35 rail installation

6, 3-way power input design

Hardware Features

Description	Specification
Model	SST-1GT4GT
Interface	41Gbps RJ45 ports 11Gbps uplink RJ45 port
Port Standard	IEEE802.3 (Ethernet) IEEE802.3u (Fast Ethernet) IEEE802.3x (Flow Control) IEEE802.3ab (Gigabit Ethernet)
Switching Bandwidth	10Gbps
Packet Forwarding Rate	7.444Mpps
Packet Buffer	3Mbit
MAC Address Table	2K
Transmission Method	Store and Forward
Power Supply	DC12~55V Power wiring: 4 PIN industrial terminals (redundant V1+V1-, V2+V2-) , DC-IN 2.1MM (DC 2.1 cannot be used simultaneously with V1 and V2)
Structure Information	Product Dimensions: 10076.530mm Packaging Dimensions: 17513055mm Product Net Weight: 0.21KG Product Gross Weight: 0.31KG
Packing Information	Carton Dimensions: 540290375mm Packing Quantity: 40PCS Packing Weight: 13.4KG

Mainboard Power Consumption	2.03W
Package Contents	Switch 1pcs, Manual 1pcs, Certificate of Inspection 1pcs
Fan Quantity	0
Installation	Desktop, Wall mounting installation, Rail installation
Surge Protection	Port Surge: Common mode 4KV, Differential mode 1KV (Class A) Electrostatic ESD: Air 8KV, Contact 6KV (Class C) Power Supply: Common mode 2KV, Differential mode 1KV (Class A)
Operating Temperature	-40~75°C
Storage Temperature	-40~85°C
Operation Humidity	10%~90%, non condensing
Storage Humidity	5%~95%, non condensing
PWR Green LED	On: Powered on Off: Powered off
Ports 1-5 Green LED	On: 10/100/1000Mbps Link normal Off: Link blocked Flashing: Data transmitting
D/E Modes Buttons	D: Normal mode, all ports can communicate with each other, transmission distance is within 100 meters, transmission rate is 10/100/1000Mbps adaptive E: Extend mode, ports 1-4 force 10Mbps to extend the transmission distance to 250meters
