1000Base-T as you require. It can extend the transmission distance, and also have many other advantages such as
isolation protection, good data security, working stability and easy maintenance.
Features:
1, Support the switch between 10/100/1000Base-T and 1000Base-SX/LX
2, 4*1.25Gbps full-duplex fiber ports and 3*1000M Ethernet ports with auto-negotiation function
3, Support MDI/MDIX and half/full-duplex with auto-negotiation function
4, Each port has the complete LED Indicator light
5, Support IEEE802.1d Spanning Tree
6, Support IEEE802.1q and VLAN division
7, Support high performance QoS function oneach port
8, Support 5-16V voltage input
9, Require no configuration and will instantly operate as soon as you power it up
10, Use Marvel chip, stable and reliable
11, Low power consumption chip with heat sink built in to ensure longtime efficient operation
Specification
|
Standards |
IEEE802.3 10Base-T IEEE802.3u 100Base-TX/FX IEEE802.3ab 1000Base-T IEEE802.3z 1000Base-SX/LX |
IEEE802.3x Flow control IEEE802.1pQoS IEEE802.1d Spanning Tree IEEE802.1q VLAN |
|
Certifications |
CCC, CE, FCC, RoHS |
|
|
Ethernet Port |
Ø Connector:RJ45 Ø Data Rate: 10/100/1000M Ø Distance: 100m Ø UTP Type:UTP-5E or higher level |
|
|
Fiber Port |
Ø Connector: SFP slot Ø Data Rate: 1.25Gbps Ø Optical Wavelength:850nm/1310nm/1490nm/1550nm Ø Distance: 550m～100km |
|
|
Performance |
Ø Processing Type : Store and Forward Ø MAC Table Size: 1K Ø Buffer Space: 1Mbit Ø Back bandwidth: 12G Ø Time Delay:＜20μs |
|
|
Power |
Ø Power type: external power supply Ø Input Voltage:AC100V～240V 50/60Hz Ø Connector:DC Socket Ø Working Voltage:5V Ø Power Consumption: 1.8W～5W |
|
|
Environment |
Ø Storage Temperature: -40～85℃ Ø Operating Temperature: -10～85℃ Ø Relative Humidity: 5-90% ( no condensation) |
|
|
Warranty |
1 year |
|
|
Physical Characteristics |
Ø Dimension: 160×84×26mm Ø Weight:0.30kg Ø Color:Metal, Black |
|
