4 ports Gigabit Ethernet Fiber Switch

4 ports Gigabit Ethernet Fiber Switch with 4 10/100/1000Mbps Ethernet ports and 1

1.25Gbps fiber port. It extends the transmission distance of a network from 550m to 120km via

fiber cables. There are also many other advantages such as isolation protection, good data security,

working stability and easy maintenance.

1, Support the switch between 10/100/1000Base-T and 1000Base-SX/LX

2, 1*1.25Gbps full-duplex fiber port and 4*1000M Ethernet ports with auto-negotiation function

3, Support 1000M speed rate,MDI/MDIX and half/full-duplex with auto-negotiation function

4, Each port has the complete LED Indicator light

5, Support single mode single fiber,single mode dual fiber,multi-mode dual fiber and SFP slot

6, Support IEEE802.1d Spanning Tree

7, Support IEEE802.1q and VLAN division

8, Support high performance QoS function on each port

9, Support multicast to avoid network congestion

10, Support 5-16V voltage input

11, Support 10K Jumbo Packet

12, Require no configuration and will instantly operate as soon as you power it up

13, Low power consumption chip with heat sink built in to ensure longtime efficient operation

Standards	IEEE802.3 10Base-T IEEE802.3u 100Base-TX/FX IEEE802.3ab 1000Base-T IEEE802.3z 1000Base-SX/LX	IEEE802.3x Flow control IEEE802.1p QoS IEEE802.1d Spanning Tree IEEE802.1q VLAN
Certifications	CCC, CE, FCC, RoHS
Ethernet Port	Ø Connector: RJ45 Ø Data Rate: 10/100/1000M Ø Distance: 100m Ø UTP Type: UTP-5E or higher level
Fiber Port	Ø Connector: SC/FC/ST/LC slot Ø Data Rate: 1.25Gbps Ø Optical wavelength: 850nm/1310nm/1490nm/1550nm Ø Distance: 550m～100km
Performance	Ø Processing Type: Store and Forward Ø MAC Table Size: 8K Ø Buffer Space: 1Mbit Ø Back bandwidth: 10G Ø Time Delay:＜20μs
Power	Ø Power type: external power supply Ø Input Voltage: AC100V～240V 50/60Hz Ø Connector: DC Socket Ø Working Voltage: 5V Ø Power Consumption: 1.8W～5W
Environment	Ø Storage Temperature: -40～70℃ Ø Operating Temperature: -10～55℃ Ø Relative Humidity: 5-90% ( no condensation)
Warranty	3 year
Physical Characteristics	Ø Dimension: 94×70×26mm Ø Weight: 0.20kg Ø Color: Metal, Black
