Gigabit 5 port SFP fiber optic switch

SST-1F4ET-SFP Gigabit 5 port SFP fiber optic switch is a 10/100/1000Mbps adaptive gigabit Ethernet Fiber Switch. It has four 10/100/1000Mbps Ethernet ports and one 1.25Gbps fiber port. Users can choose different SFP modules in need. It can extend the transmission distance; there are also many other advantages such as isolation protection, good data security, working stability and easy maintenance.

Feature

1, Support the switch between 10/100/1000Base-T and 1000Base-SX/LX

2, 1*1.25Gbps full-duplex fiber port and 4*1000M Ethernet ports with auto-negotiation function

3, Support 1000M speed rate,MDI/MDIX and half/full-duplex with auto-negotiation function

4, Each port has the complete LED Indicator light

5, Support single mode single fiber,single mode dual fiber,multi-mode dual fiber and SFP slot

6, Support IEEE802.1d Spanning Tree

7, Support IEEE802.1q and VLAN division

8, Support high performance QoS function on each port

9, Support multicast to avoid network congestion

10, Support 5-16V voltage input

11, Support 10K Jumbo Packet

12, Require no configuration and will instantly operate as soon as you power it up

13, Low power consumption chip with heat sink built in to ensure longtime efficient operation

Specification

Model	SST-1F4ET-SFP
Product	Full Gigabit 4+1 Switch
Fixed Port	410/100/1000Base--TX RJ45 port (Data) 11000M Integrated SFP(optional 1310/1550)
Network Protocol	IEEE802.3 IEEE802.3i 10BASE-T IEEE802.3u100BASE-TX IEEE 802.3ab1000BASE-T IEEE802.3x IEEE 802.3z 1000BASE-X
Port Specification	100/1000BaseT(X) Auto
Transmission Mode	Store and Forward(full wirespeed)
Bandwidth	2.5Gbps
Packet Forwarding	12.96Mpps
MAC Address	2K
Buffer	2.5M
Transmission Distance	10BASE-T : Cat3,4,5 UTP(≤250 meter) 100BASE-TX : Cat5 or later UTP(150 meter) 1000BASE-TX : Cat6 or later UTP(150 meter) Single mode single fiber(MAX 20KM) Single mode double fiber (MAX 20KM) Multiple mode double fiber(MAX 850M/2KM) Optional 3-100KM SFP
Watt	≤10W;
LED Indicator	PWR:Power LED FX1/FX2:(SFP LED) Port :(Green=10/100M LED+Orange=1000M LED)
Power	External power DC 5V 2A
Operating Temperature/Humidity	-15~+65°C;5%~90% RH Non coagulation
Storage Temperature/Humidity	-40~+75°C;5%~95% RH Non coagulation
Productsize/Packing size(LWH)	178mm98mm225mm 270mm162mm55mm
N.W/G.W(kg)	0.5kg/0.64kg
Installation	Desktop (optional wall hanger+machine hanger parts)
Lightning Protection level	3KV 8/20us; IP30
Certificate	CE mark, commercial;CE/LVD EN60950; FCC Part 15 Class B;RoHS;MA;CNAS
Warranty	Whole device for 3 year
