Ethernet ports and two 1.25Gbps fiber ports. It extends the transmission distance of a network from 100m to120km
via copper cables. There are also many other advantages such as isolation protection, good data security, working
stability and easy maintenance.
Product Feature
1, Support the switch between 10/100/1000Base-TX and 1000Base-SX/LX2, 2*1.25Gbps full-duplex fiber ports and 2*1000M Ethernet ports with auto-negotiation function
3, Support MDI/MDIX and half/full-duplex with auto-negotiation function
4, Each port has the complete LED Indicator light
5, Support single mode single fiber,single mode dual fiber,multi-mode dual fiber and SFP slot
6, Support IEEE802.1d Spanning Tree
7, Support IEEE802.1q and VLAN division
8, Support high performance QoS function on each port
9, Support broadcast storm control
10, Support 5-16V voltage input
11, Support 10K Jumbo Packet
12, Support 8K MAC table
13, Support IEEE802.3x flow control and back pressure control
14, Require no configuration and will instantly operate as soon as you power it up
15, Low power consumption chip with heat sink built in to ensure longtime efficient operation.
Specifications:
|
Model |
SST-2F2ET-SFP |
|
Product |
Full Gigabit 2+2 fiber Optic Switch |
|
Fixed Port |
2*10/100/1000Base--TX RJ45 port (Data) 2*1000M Integrated SFP |
|
Network Protocol |
IEEE802.3 IEEE802.3i 10BASE-T IEEE802.3u100BASE-TX IEEE 802.3ab1000BASE-T IEEE802.3x IEEE 802.3z 1000BASE-X |
|
Port Specification |
100/1000BaseT(X) Auto |
|
Transmission Mode |
Store and Forward(full wirespeed) |
|
Bandwidth |
8Gbps |
|
Packet Forwarding |
12.96Mpps |
|
MAC Address |
2K |
|
Buffer |
2.5M |
|
Transmission Distance |
10BASE-T : Cat3,4,5 UTP(≤250 meter) 100BASE-TX : Cat5 or later UTP(150 meter) 1000BASE-TX : Cat6 or later UTP(150 meter) Single mode single fiber(MAX 20KM) Single mode double fiber (MAX 20KM) Multiple mode double fiber(MAX 850M/2KM) Optional 3-100KM SFP |
|
Watt |
≤10W; |
|
LED Indicator |
POWER:Power LED SFP1/SFP2:(SFP LED) Port :(Green=10/100M LED+Orange=1000M LED) |
|
Power |
External power DC 5V 2A |
|
Operating Temperature/Humidity |
-15~+65°C;5%~90% RH Non coagulation |
|
Storage Temperature/Humidity |
-40~+75°C;5%~95% RH Non coagulation |
|
Product size /Packing size(L*W*H) |
113mm*92mm*28mm 230mm*125mm*55mm |
|
N.W/G.W(kg) |
0.33kg/0.46kg |
|
Installation |
Desktop (optional wall hanger+machine hanger parts) |
|
Lightning Protection level |
3KV 8/20us; IP30 |
|
Certificate |
CE mark, commercial;CE/LVD EN60950; |
|
Warranty |
Whole device for 3 year |
