Shenzhen SunSoont Technology Co., Ltd
Product Features
1, Support the switch between 10/100/1000Base-T and 1000Base-SX/LX2, 2*1.25Gbps full-duplex fiber ports and 4*1000M Ethernet ports with auto-negotiation function
3, Support 1000M speed rate, MDI/MDIX and half/full-duplex with auto-negotiation function
4, Each port has the complete LED Indicator light
5, Fiber port support SFP modules
6, Support IEEE802.1d Spanning Tree
7, Support IEEE802.1q and VLAN division
8, Support high performance QoS function on each port
9, Support 5-16V voltage input
10, Support 10K bytes Jumbo Packet
11, Require no configuration and will instantly operate as soon as you power it up
12, Small volume, light weight
13, Low power consumption chip with heat sink built in to ensure longtime efficient operation.Specification
|
Model |
SST-2F4ET-SFP |
|
Product |
Full Gigabit 4+2 Switch |
|
Fixed Port |
4*10/100/1000Base--TX RJ45 port (Data) 2*1000M Integrated SFP(optional 1310/1550) |
|
Network Protocol |
IEEE802.3 IEEE802.3i 10BASE-T IEEE802.3u100BASE-TX IEEE 802.3ab1000BASE-T IEEE802.3x IEEE 802.3z 1000BASE-X |
|
Port Specification |
100/1000BaseT(X) Auto |
|
Transmission Mode |
Store and Forward(full wirespeed) |
|
Bandwidth |
12Gbps |
|
Packet Forwarding |
12.96Mpps |
|
MAC Address |
2K |
|
Buffer |
2.5M |
|
Transmission Distance |
10BASE-T : Cat3,4,5 UTP(≤250 meter) 100BASE-TX : Cat5 or later UTP(150 meter) 1000BASE-TX : Cat6 or later UTP(150 meter) Single mode single fiber(MAX 20KM) Single mode double fiber (MAX 20KM) Multiple mode double fiber(MAX 850M/2KM) Optional 3-100KM SFP |
|
Watt |
≤10W |
|
LED Indicator |
PWR:Power LED FX1/FX2:(SFP LED) Port :(Green=10/100M LED+Orange=1000M LED) |
|
Power |
External power DC 5V 2A |
|
Operating Temperature/Humidity |
-15~+65°C;5%~90% RH Non coagulation |
|
Storage Temperature/Humidity |
-40~+75°C;5%~95% RH Non coagulation |
|
Product size/Packing size(L*W*H) |
178mm*98mm*225mm 270mm*162mm*55mm |
|
N.W/G.W(kg) |
0.5kg/0.64kg |
|
Installation |
Desktop (optional wall hanger+machine hanger parts) |
|
Lightning Protection level |
3KV 8/20us; IP30 |
|
Certificate |
CE mark, commercial;CE/LVD EN60950; |
|
Warranty |
Whole device for 3 year |
