Ethernet ports. Users can select different optical modules according to their actual needs, etc. All ports
support line speed forwarding and MDI / MDIX automatic flip function. Product plug and play, simple to use,
without any settings. This series of switches adopts 19-inch standard frame design and can be on the rack.
Product Features
1, 10/100/1000M rate adaptive, MDI / MDIX adaptive, full / half-duplex adaptive ;
There are 9 10/100/1000M adaptive RJ45 ports and 16 SFP ports;
2, Automatic identification of parallel lines / cross lines (MDI / MDIX) to simplify the erection and maintenance of the network;
3, Complete LED indicator light, LINK / ACT indicator light, power supply indicator light;
4, Support IEEE802.1d generation tree (Spanning Tree) protocol, make networking easier;
5, Support for QoS, to ensure the efficient operation of the network; > All ports have support lines. Fast exchange;
6, Supports 4K VLAN tables based on the IEEE802. 10 port protocol;
7, Support for broadcast storm suppression;
8, Support for up to 2K port lightning protection;
9, Support VLAN isolation, prevent the ring road, effectively solve the network congestion and jam caused by the broadcast storm;
10, Simple to use, plug and play, without any Settings;
11, Standard mountain frame design, convenient cabinet installation
Protocol Standard
IEEE802.3 10Base-T
lEEE802.3u 100Base-T/FX
lEEE802.3ab 1000Base-T
IEEE802.3Z 1000Base-SX/LX
IEEE802.3x Flow control
IEEE802.1q VLAN
IEEE802.1p QoS
IEEE802.1d Spanning Tree
Electric port parameters
Port connector: 9*RJ45
Transmission rate: 10/100/1000Mbps Adaptive
Cable type: UTP-5E or higher level
Transmission distance: 100 meters
Fiber port
parameters
16*Gigabit SFP ports
Transmission rate: 1.25Gbps
Support 1.25G SFP module
Light mouth
parameters
Optical port connector: SFP slot Capture rate: 1.25 Gbps
Optical wavelength: 850nm / 1310nm / 1490nm /1550nm
Fiber type: single-mode 9/125m, multi-mode 50/125 m, 62.5/125 m
Performance
specification
Forwarding mode: store and forward
Transmission mode: full-duplex / half-duplex adaptive
Frame memory: 4.1 Mbit
Support for giant frame: 10K
Backplane bandwidth: 50G
Power Source
Power supply type: Built-in power supply
Power supply input voltage: AC100V- -240V 50 / 60 HZ
Machine power connector: AC socket
Power consumption of the machine: 5.76W 20W
Work
environment
Storage temperature: -30~80°C
Operating temperature: -10~70°C
Working humidity: 5%~90% no condensation
Physical construction
Size: 490x140x45mm
Single gross Weight: 2.1kg
Body color: metal, black
Specification
Model number
SST-16F9ET
