10-Ports 10/100/1000Mbps POE Switch, using high-quality high-speed network IC and the most stable POE chip,
POE port meets 802.3af / 802.3at standard, this series of POE Switch can be 10/100/1000Mbps Ethernet. The
network provides a seamless connection, and the POE power port can automatically detect and power the powered
devices that comply with the IEEE802.3af / IEEE802.3at standards. The non-POE device intelligently detects no power
and only transmits data.

POE (Power over Ethernet) refers to the technology of providing dc Power supply to some IP-based terminals (such as
IP telephone, wireless access AP, network camera, etc.) while transmitting data signals. These devices receiving dc Power
supply are called receiving devices.

With simple and convenient installation and maintenance methods and rich business features, it helps users to build a safe
and reliable high-performance network. It is mainly located in the core or convergence layer of user networks such as industrial
]parks, buildings, factories and mines, government agencies, and residential broadband; it can be widely used in Ethernet access
scenarios such as small and medium-sized enterprises, Internet cafes, hotels, and schools.


Product Feature

8*10/100/1000Mbps POE Ports + 2*10/100/1000Mbps Ethernet Uplink Ports

Flow control mode: full-duplex adopts IEEE 802.3x standard, half-duplex adopts Back pressure standard

Support port auto flip (Auto MDI/MDIX)

Exchange mechanism using store-and-forward

All ports support wire-speed switching

Automatically supplied to adaptive devices

Panel indicator monitoring status and help failure analysis.


Product Technical Parameter
